Description
25/50 Ports Cat3 Voice Patch Panel
Specifications:
☆Meet TIA/EIA-568-A and TIA/EIA-568-B category 3 requirements
☆Meet TIA/EIA TSB-40
☆Meet ISO/IEC Generic Cabling Standard 11801
☆Meet CENELEC Generic Cabling Standard EN50173
☆Angle: 90 Degree
☆Termination: Krone type
Materials:
☆According to UL 1863
☆Current rating: 1.5 Amp Max
☆Voltage rating: 150 Volts
☆Contact resistance: 20m-ohm
☆Insulation resistance: 500M-ohm
☆Dielectric Withstand Voltage: 1000VAC RMS, 60Hz 1min
Electrical:
☆Housing:PC UL94V-0
☆IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire
☆PCB: FR4 1.6mm(0.04″)thickness, 2 layers
☆Contact PC UI94V-0, 0.45mm(0.018 “)Diameter Phosphor
bronze with 3 u”to 50 u”Gold plating on contact area
–
–
